The main material is SUS304 sanitary stainless steel;
Effective volume: 45BBL, Full volume: 54BBL;
The top and the bottom of tank is made of stainless-steel dished head, with 100% TIG welding; cleaning and polishing;
DDesign Pressure: 0.2MPa Test Pressure: 0.4MPa;
4 x heavy-duty stainless-steel scaffold with adjustable height and horizontal support;
Thickness of Tank: 3mm for interior shell;
Heat Insulation: Polyurethane Foaming Insulation with the thickness ranges from 80mm to 100mm.
The thickness of out cladding: 2mm;
Internal and external surfaces shall be clean and polished, and internal surface shall be polished up to 0.4um;
According to the specification of tank type, the corresponding specification and model of sanitary clamp joints would be equipped;
Equipped with vacuum valve / pressure relief valve, pressure gauge, temperature gauge, sampling valve, lifting lug, side or top maintenance manhole, all-round equipment cleaning CIP nozzle with 360 degree;
Equipped with the double inlet and double outlet glycol cooling pipe;
Coolant Jacket: Welded Honeycomb Maitre Sandwich Plat;
Outlet feeder port with valves and accessories;
Equipped with electronic thermometer sensing interface;
CO2 charging device.
