Use and characteristics:
GD pipe bundle drying machine series, according to the current heating mode operation.Has been in the chemical industry, light industry, food, food processing, feed and other industries for loose material drying technology has been widely used in the operation, such as liquor worse, pig hair, bone powder, granular or powder fertilizer, inorganic minerals, especially corn processing industry of corn fiber, germ, protein powder, feed industry of carrier material, fish and shrimp scraps, rapeseed (not the seeds), etc., they can be powder, granule, flake or other content without large viscous loose materials.
GD series dryer has absorbed the advantages of similar products abroad, and a certain degree of improvement.The machine main advantage is that low heat consumption, high efficiency and energy saving, dry the wide range of materials, processing capacity is big, water evaporation capacity is big and high moisture drying, drying elasticity can (depending on the different material properties and water requirements to adjust the drying time), continuous operation (that is, a high degree of automation), intermittent operation (suitable for special process).The machine less additional equipment, covers an area of less, process layout is compact, can be placed on a single plant, thus greatly save the construction cost, in addition the machine process, few wear parts, easy to install, low maintenance cost.
Dry operation the yuan:
Continuous operation, for special materials can be intermittent operation.Less auxiliary equipment, the cluster type host cover an area of an area small, processing capacity, energy conservation and low consumption.
Mode of heat transfer: non-contact heat conduction and thermal radiation
The heating medium: saturated steam
Wet material into the machine after to dehydration treatment, is the effective measure to reduce the total energy consumption of drying and reasonable process arrangement
Wet material into the mixture screw with right amount after mixing of dry material, the feed screw into the machine, which can effectively avoid the wall is wet material, improve the dry operating condition.
Suitable for operation of the material should be the one for loose material, can be powder, granule, flake, material or other monomers
Bundle steam flow to the inside and outside the tube bundle material flows to the opposite: low speed rotation of tube bundle through the servo feeding shovel not stop changes the material and to import the discharging mouth direction in steam continuous feeding and discharging.
Applications for
Corn starch industry: dry germ, protein powder dry, dry fiber, dry corn feed (fiber + + soaking by to the enrichment of corn gluten liquid + syrup, etc.)
The alcohol industry: drying alcohol and lees feed
Processing: dry beer worse
Extraction enterprises: to deal with beans, for the treatment of sunflower seeds, grant processing rapeseed, to deal with other oil fruits
Dry chemical and plastics industry: all kinds of raw materials the product particles
Wood: dry wood chips
The basic composition unit:
GD hosts, steam and condensate system, steam and dry matter recycling hydrocyclone heat exchanger for the optional parts (heat exchanger).
